Yamaha Engine Hardware
by Aftermarket
SKU
Original price
$2.03
-
Original price
$6.11
Original price
$2.03
$2.03
-
$6.11
Current price
$2.03
| REF # | DESCRIPTION | SIZE | PITCH | REQ'D |
| Yamaha 650/701 Early Models | ||||
| A | Head Hex Head Bolt | 8 x 50 | 1.25 | 10 |
| B | Cylinder Hex Head Bolt | 10 x 40 | 1.25 | 4 |
| C | Cylinder Hex Head Bolt | 10 x 55 | 1.25 | 2 |
| D | Crankcase Hex Head Bolt | 8 x 85 | 1.25 | 10 |
| Yamaha 701 WaveRaider | ||||
| B | Cylinder Hex Head Bolt | 10 x 40 | 1.25 | 4 |
| C | Cylinder Hex Head Bolt | 10 x 55 | 1.25 | 2 |
| D | Crankcase Hex Head Bolt | 8 x 85 | 1.25 | 10 |
| E | Crankcase Hex Head Bolt | 8 x 45 | 1.25 | 8 |
| Yamaha 800 GP/XL | ||||
| D | Crankcase Hex Head Bolt | 8 x 85 | 1.25 | 10 |
| F | Crankcase Hex Head Bolt | 6 X 80 | 1.25 | 3 |
| Yamaha 1100/1200 (NPV) | ||||
| A | Head Hex Head Bolt | 8 x 50 | 1.25 | 10 |
| B | Cylinder Hex Head Bolt | 8 x 85 | 1.25 | 6 |
| C | Cylinder Hex Head Bolt | 10 x 55 | 1.25 | 2 |
| D | Crankcase Hex Head Bolt | 8 x 85 | 1.25 | 10 |
| G | Head Hex Head Bolt | 8 x 65 | 1.25 | 4 |
